Technical Parameters
| Item Number | Model | Style | Rated Load (kN) | Outer Diameter × Sheave Width (mm) | Weight (kg) |
| 11251 | QH1GL-1 | Single sheave, open, hook | 10 | Φ100×31 | 2.2 |
| 11252 | QH2GL-1 | Twin sheave, hook | 10 | Φ80×27 | 2.3 |
| 11253 | QH2HL-1 | Twin sheave, ring | 10 | Φ80×27 | 1.9 |
| 11261 | QH3GL-1.5 | Triple sheave, hook | 15 | Φ80×27 | 3 |
| 11262 | QH3HL-1.5 | Triple sheave, ring | 15 | Φ80×27 | 2.6 |
| 11271 | QH3GL-2 | Triple sheave, hook | 20 | Φ100×31 | 4.5 |
| 11272 | QH3HL-2 | Triple sheave, ring | 20 | Φ100×31 | 3.5 |
| 11273 | QH2GL-2 | Twin sheave, hook | 20 | Φ100×31 | 3.6 |
| 11274 | QH2HL-2 | Twin sheave, ring | 20 | Φ100×31 | 3 |
| 11275 | QH1HL-2 | Single sheave, open, ring | 20 | Φ120×35 | 3.4 |
